General
Brand
|
: |
INDEKS |
Model
|
: |
IND JV 110 |
Stand-by Power
|
: |
110 KVA |
Prime Power
|
: |
100 KVA |
Engine
| Manufacturer |
|
Volva Penta |
| Model |
: |
TAD531GE |
| Stand-by Power |
: |
96 KW / 128 Hp |
| Prime Power |
: |
88 KW / 118 Hp |
| Speeed(Rpm) |
: |
1500 rpm |
Cylinder Number/ Arrangement
|
: |
4 Line |
Bore x Stroke
|
: |
108mm x 130mm |
| Displacement |
: |
4.76 lt |
Aspiration and Cooling
|
: |
Turbo Charged |
Compression Ratio
|
: |
18:01 |
Governor Type
|
: |
Mechanical/Electronic |
Cooling System
|
: |
Water cooled |
Oil System Capacity(Including Filiters)
|
: |
13 Lt |
Lubricating Oil Consumption
(Prşme Power)
|
: |
0.08 Lt/h |
| Fuel System |
: |
Direct Injection |
| Fuel Consumption (%50 of Prime Power) |
: |
221 g/KWh |
| Fuel Consumption (%75 of Prime Power) |
: |
217 g/KWh |
| Fuel Consumption (%100 of Prime Power) |
: |
219 g/KWh |
| Air Consumption(at Stand-By Power/25oC) |
: |
215 m³/h |
| Exhaust Gas Flow(at Stand-By Power) |
: |
18.4 m³/min |
| Exhaust Gas Tempereture |
: |
557 ºC |
| Type |
: |
Brushless, Synchr. |
Excitation System
|
: |
Self Exciting |
| Frequence |
: |
50 Hz |
| Voltage |
: |
231/400 V |
| Speed |
: |
1500 rpm |
Excessive Loading Capacity
|
: |
For 1 Hour % 110, For 2 Minutes %150 |
Protection Class
|
: |
IP23 |
Insulation Class
|
: |
H |
Chassis
• Steel chassis and antivibration pads
• Base frame design incorporates an fuel tank (fuel gauge and drain plug on the fuel tank)
• Military / Civilian type easy lifting systems |
Control System
• Control supervision and protection panel is mounted on the genset base freme.
• Indeks brand micro processed control unit.
• Standart indicators, alarms, buttons, keys
• Useful design for Automatic / Manuel working
** Please reguest for more information
|
Dimensions & Weight
| Width (mm) |
: |
875 mm |
| Lenght (mm) |
: |
2100 mm |
| Height (mm) |
: |
1550 mm |
Weight(kg)
(Without Canopy)
|
: |
1270 kg |
Optional Equipment
• Sound proof canopy
• Trailer
• Silencer
• Alternator Heater
• Main fuel tank
• Tool kit
• Oil and Fuel filling / drain pump
